VigiSight � image processing

VigiSight OEM:

Application:�OEM
IP:�00
Number of camera:� 4 video IP SXGA
connecting:�industrial connecting – 1 connector “video in” – 1 monitoring input DVI/VGA – 1 video output HDMI/PAL
Power Supply:� 30 W
Voltage:� 5V DC
Weight:� 0.3 kg
Dimensions (mm):� 115 x 95 x 90
Operating T�: -40�C to + 85�C

VigiSight 50:

Application:�indoor
IP: 50
Number of camera: 1 video analog SVGA
connecting:� Military connecting – 1 connector “video in ” – 1 video PAL SVGA
Power Supply:� 50 W
Voltage:� 10 to 28V DC
Weight:� 6.1 kg
Dimensions (mm):� 205 x 380 x 90
Operating T�: -30�C to + 70�C

VigiSight 65:

Application:�outdoor or vehicle
IP: 65
Number of camera: 4 video IP SXGA
connecting: Military Connecting – 1 connector “video in ” – 1 video output IP
Power Supply:� 30 W
Voltage:� 9 to 33V DC
Weight: 4.1 kg
Dimensions (mm): 220 X 290 x 190
Operating T�: -32�C to + 65�C

VigiSight is compatible with any day or night camera. The system offers users key advantages:

detection and tracking of moving vehicles / person at a long distance
self-tuning to align with operating situations
highly intuitive and user-friendly interface
improved operator vigilance.

VigiSight makes it possible to equip any camera with analogical video (PAL/NTSC) or digital (IP) output with real-time processing functions, day or night. It comes with three models depending on the civil or military applications, and is equipped with intelligent alarming with virtual zones and barriers. Automatic detection of target and tracking is available with fixed or scanning cameras. VigiSight can detect up to 10 simultaneous objects.

Reasons to choose VigiSight � image processing

Night & day surveillance capability (24/7)

Detection distance from 10 m up to 9 km

Large Field of View (FOV) up to 360� for cameras equipped with a Pan&Tilt

Network deployment for surveillance of large zones
